GR-1435, GR-1221 compliant

Transmission mode: multi-channel serial and parallel transmission mode

High accuracy,

Support：12 x 1.25~3.5G, 2X40G(4x10G), 2X100G(4x25G), 10X10G, 12x10G, 4x32G，8X10G，8X25G，8X50G，8X100G

Connector A: MT ferrule with guide pin

Connector B: Customized Jumper/Lens, Usconect Prizm/Lensed MT

Fiber shape: ribbon

Fiber count: 2F/4F/8F/12F/16F/24F

Fiber type: OM3, OM4; OM1, OM2; OS1,OS2; PM;OM5；

Length: 20~100mm, and customized length available

Length tolerance: +500um/-0um

Passive optical interconnect jumpers can be deployed in QSFP, QSFP28, QSFP-DD, Micro QSFP, CXP, CFP, CDFP, and any parallel optical transceiver modulesPassive optical interconnect jumpers can be deployed in QSFP, QSFP28, QSFP-DD, Micro QSFP, CXP, CFP, CDFP, and any parallel optical transceiver modules, supporting various network types, including Ethernet optical network, Infiniband optical network, and Fiber Channel network. , supporting various network types, including Ethernet optical network, Infiniband optical network, and Fiber Channel network.
